Updated two-way file flow in latest WORKXPLORE

Published: 04 November 2019

Easier and more interactive printing

Specific simulation import, a couple of additional reader translators and client viewer measurements all feature in a number of enhancements in the latest release of WORKXPLORE, the powerful high-speed CAD viewer and analyser from Hexagon’s Production Software portfolio.

The software was originally created to efficiently import and analyse all file types and sizes at high speed. It often takes less than half the time to open a file compared to the original CAD application.

Amongst the new and enhanced two-way workflow functionality in WORKXPLORE 2020.1 is the ability to import and export the IGP file format for the Hexagon I++ Simulator, which is a server-based software for multi-kinematic simulation of process-oriented inspections to automate production metrology.

WORKXPLORE can export either opened or closed solids, mesh models as meshes, as well as meshes. Additional reader translators include Solid Edge 2D Importer, and the IGES Reader Translator. The ability to read drawings has been added to the Solid Edge interface. Currently, 2D supported versions are ST1 to 2019. While the IGES translator allows users to choose between the in-house integrated import library and the Datakit Advanced Import, giving a choice for the setting best suited to specific needs.

A Print Option enhancement gives more interactive printing functionality in the single view layout, by manipulating entities over the printing. Product owner Luca Clerici says: “The printing zone in WORKXPLORE 2020.1 can be defined through an interactive rectangle, with the ability to move the camera in the 3D screen.

“When the command is launched, a mask corresponding to the paper ratio, for example A4 landscape, appears onscreen. It’s then possible to move the model to precisely define the printing area. Also, another interactive rectangle provides an optional crop facility.”

A toolbar with the print options is now available on the right side of the screen, making it easier to select the target printer and define its properties, select the paper size and add headers and footers. He says that another important new function enables measurements done in WORKXPLORE can now be export to the Client Viewer.

This release also continues the software’s tradition of constantly updating supported formats. Translators in WORKXPLORE 2020.1 support a number of main formats, including: ACIS, several CATIA products, Creo, DXF/DWG, IGES, EDGECAM, I++ Simulator, INVENTOR, Parasolid, STEP, Solid Edge and SolidWorks.
